7 Optional Modules
7.1 OM1 and OM2
Optional extensions are possible at the slots OM1 and OM2.
Fig.7-1: Positions of OM1, OM2
Optional extension OM1 OM2
Digital I/O Extension ■ ■
Fig.7-2: Optional Extensions
