1.6.3 Documentations
Drive Systems, System Components
Drive Systems with Multi-Axis Drive Controllers
Title Kind of documentation
Document typecode
1)
Part number
R911…
Rexroth IndraDrive
Drive Controllers HCQ02, HCT02
Project Planning Manual DOK-INDRV*-HCQ-T+HMQ-T-
PRxx-EN-P
324185
Rexroth IndraDrive
Additional Components and Accesso‐
ries
Project Planning Manual DOK-INDRV*-ADDCOMP****-
PRxx-EN-P
306140
Rexroth IndraControl VDP 80.1
Machine Operator Panel
Operator Display
Project Planning Manual DOK-SUPPL*-VDP*80.1***-PRxx-
EN-P
329156
1) In the document typecodes, "xx" is a wild card for the current edition of
the documentation (example: PR01 is the first edition of a Project
Planning Manual)
Fig.1-8: Documentations – Drive Systems, System Components
Motors
Title
Rexroth IndraDyn …
Kind of documentation
Document typecode
1)
DOK-MOTOR*-…
Part number
R911…
A Asynchronous Motors MAD / MAF Project Planning Manual MAD/MAF****-PRxx-EN-P 295781
H Synchronous Kit Spindle Motors Project Planning Manual MBS-H******-PRxx-EN-P 297895
L Synchronous Linear Motors Project Planning Manual MLF********-PRxx-EN-P 293635
L Coreless Linear Motors MCL Project Planning Manual MCL********-PRxx-EN-P 330592
S Synchronous Motors MKE Project Planning Manual MKE*GEN2***-PRxx-EN-P 297663
S Synchronous Motors MSK Project Planning Manual MSK********-PRxx-EN-P 296289
S Synchronous Motors MSM Data Sheet MSM********-DAxx-EN-P 329338
S Synchronous Motors QSK Project Planning Manual QSK********-PRxx-EN-P 330321
T Synchronous Torque Motors Project Planning Manual MBT********-PRxx-EN-P 298798
1) In the document typecodes, "xx" is a wild card for the current edition of
the documentation (example: PR01 is the first edition of a Project
Planning Manual)
Fig.1-9: Documentations – Motors
Cables
Title Kind of documentation
Document typecode
1)
DOK-CONNEC-…
Part number
R911…
Rexroth Connection Cables Selection Data CABLE*INDRV-CAxx-EN-P 322949
1) In the document typecodes, "xx" is a wild card for the current edition of
the documentation (example: CA02 is the second edition of the docu‐
mentation "Selection Data")
Fig.1-10: Documentations – Cables
