8.4 External Braking Resistor
Braking Resistor, Data
Description Value
Allowed braking resistance 10 … 17 Ω
Allowed peak regenerative power < 69 kW
Allowed regenerative power of braking resistor < 100 kWs
Allowed continuous power load of connection point X9 < 5 kW
Allowed cable length 5 m
Fig.8-3: External Braking Resistor
Notes on Installation
See description of connection point X9.
Bosch Rexroth AG DOK-INDRV*-HCQ-T+HMQ-T-PR03-EN-P
Rexroth IndraDrive Drive Controllers HCQ, HCT
94/145
Notes on Project Planning
