Description Symbol Unit HCQ02.1E-W0025-_-03
Mains voltage three-phase at TN-
S, TN-C, TT mains
U
LN
V 200...500
Mains voltage three-phase at IT
mains
1)
U
LN
V 200...230
Mains voltage three-phase at Cor‐
ner-grounded-Delta mains
2)
U
LN
V 200...230
Tolerance rated input voltage (UL) % ±10
Minimum inductance of the mains
supply (inductance of mains
phase)
3)
L
min
µH 40
Assigned type of mains choke HNL01.1E-0400-N0051-A-480
Minimum short circuit power of the
mains for failure-free operation
S
k_min
MVA 1,6
Assigned type of mains filter NFD03.1-480-055; HNF01.1A-F240-E0051-A480
Inrush current
I
L_trans_max
_on
A 25,5 ... 77,8
Maximum allowed ON-OFF cycles
per minute
4)
1
Power factor TPF (λ
L
) at P
DC_cont
with mains choke; U
LN_nenn
TPF 0,82
Power factor TPF (λ
L
) at P
DC_cont
without mains choke; U
LN_nenn
5)
TPF 0,64
Power factor TPF (λ
L
) at 10%
P
DC_cont
without mains choke;
U
LN_nenn
6)
TPF
10%
0,40
Power factor of fundam. compo‐
nent DPF at P
DC_cont
with mains
choke
cosφ
h1
0,97
Power factor of fundam. compo‐
nent DPF at P
DC_cont
without mains
choke
cosφ
h1
0,97
Mains connection power at
P
DC_cont
; U
LN_nenn
with mains choke
S
LN
kVA 30,00
Mains connection power at
P
DC_cont
; U
LN_nenn
without mains
choke
S
LN
kVA 23,50
Rated input current (UL)
I
LN
A 44,0
Nominal current AC1 for mains
contactor at nom. data
I LN
Mains fuse according to
EN 60204‑1
A 50
Last modification: 2011-11-30
Bosch Rexroth AG DOK-INDRV*-HCQ-T+HMQ-T-PR03-EN-P
Rexroth IndraDrive Drive Controllers HCQ, HCT
46/145
Technical Data of the Components
