REXROTH IndraDrive HCQ02 - Notes on Project Planning

Signal Assignment
Connection Optional module
OM1 OM2
X73.1 I57 I89
X73.2 I58 I90
X73.3 I59 I91
X73.4 I60 I92
X73.5 I61 I93
X73.6 I62 I94
X73.7 I63 I95
X73.8 I64 I96
X74.1 I49 I81
X74.2 I50 I82
X74.3 I51 I83
X74.4 I52 I84
X74.5 I53 I85
X74.6 I54 I86
X74.7 I55 I87
X74.8 I56 I88
X75.1 I41 I73
X75.2 I42 I74
X75.3 I43 I75
X75.4 I44 I76
X75.5 I45 I77
X75.6 I46 I78
X75.7 I47 I79
X75.8 I48 I80
X76.1 I33 I65
X76.2 I34 I66
X76.3 I35 I67
X76.4 I36 I68
X76.5 I37 I69
X76.6 I38 I70
DOK-INDRV*-HCQ-T+HMQ-T-PR03-EN-P
Rexroth IndraDrive Drive Controllers HCQ, HCT
Bosch Rexroth AG 89/145
Optional Modules
