2. Parameter setting
Setting the direction
of rotation
If the motor rotation direction opposite to the
actual needs, set 1.
0:Position mode,1:velocity mode,2:torque mode
Selection of
command pulse input
0:Photo-coupler input
(PULS1,PULS2,SIGN1,SIGN2)
1:Exclusive input for line driver
(PULSH1,PULSH2,SIGNH1,SIGNH2)
Command pulse input
mode setup
Set command pulse input mode:command
pulse+command direction,negative ligic.
Command pulse No.
per motor circle
When it is set to ―0‖,parameters Pr0.09 and
Pr0.10 are valid
1st numerator of
command pulse
frequency
multiplication
Need
calculatio
n
Range:0~
2
30
Z1 = Encoder resolution
Z2 = Pulse equivalent×Screw pitch×Transmission
ratio
e.g. Pulse equivalent 1000,Screw pitch 10mm,
Encoder resolution 10000,Transmission ratio 1
Z1/Z2= 10000/1000×10×1=1/1
set Pr0.09=1,set Pr0.10=1.The value of Pr0.09
and Pr0.10 must be integer,range: 0~230 .
Denominator of the
command pulse
frequency
multiplication
Need
calculatio
n
Range:0~
2
30
Function setting for
digital input pin SI6
Bit1,0 :Set 83,servo on all the time.
NOTES:
1. ALM+:pin-37,ALM-:pin-36,normally closed.
