Instructions：
The signal cable of tool sensor connects to X4(X5-A18), alligator clip connects to
GND-INPUT SIGNAL.（alligator clip also can be cliped on the spindle if the spindle connected to
GND）
Place tool sensor onto workpiece,move Z axis to the upper side of the tool sensor in manual
mode,and press ― ‖+― ‖ to start Z-axis automatic tool setting,the system will
automatically set the workpiece origin of Z axis.
Mobile calibration usually use simple tool sensor which is affordable, easy and convenient.
Precautions：
Do not rush to make the alligator cliped to the spindle, start the function of tool setting
firstly,and then use the alligator clip to touch the spindle,confirm that Z axis tool setting functcan
is carried out normally.
C.A.D. Thickness system default is 0,user need to set it in ―MACHINE SEUTP- C.A.D.
Thickness‖according to actual value.
