Bit Switches
SM 61 D432/D433
D432/D433
Fax Option
Type
C2550/C2530
1
Not used
Japan Only
2
Not used
Do not change the factory settings.
3
TTI printing type
0: Address unit
1: File unit
TTI printing unit can be selected.
4-6
Not used
Do not change the factory settings.
7
Not used
Japan Only
System Switch 12 [SP No. 1-101-019]
No FUNCTION COMMENTS
0-7
TTI printing position in the
main scan direction
TTI: 08 to 92 (BCD) mm
Input even numbers only.
This setting determines the print start position for
the TTI from the left edge of the paper. If the TTI is
moved too far to the right, it may overwrite the file
number which is on the top right of the page. On
an A4 page, if the TTI is moved over by more than
50 mm, it may overwrite the page number.
System Switch 13 - Not used (do not change these settings)
System Switch 14 - Not used (do not change these settings)
System Switch 15 [SP No. 1-101-022]
No FUNCTION COMMENTS
0
Not used
Do not change the settings.
1
Going into the Energy Saver
mode automatically
0: Enabled
1: The machine will restart from the Energy Saver
mode quickly, because the +5V power supply is
active even in the Energy Saver mode.
