Bit Switches
D432/D433 98 SM
IP-Fax Switch 01
No. FUNCTION COMMENTS
Select IP FAX Delay Level
Bit3 Bit2 Bit1 Bit0 Setting
0 0 0 0 Level 0
0 0 0 1 Level 1
0 0 1 0 Level 2
0 0 1 1 Level 3
0-3
Raise the level by selecting a higher setting
if too many transmission errors are occurring
on the network.
If TCP/UDP is enabled on the network, raise
this setting on the T.30 machine. Increasing
the delay time allows the recovery of more
lost packets.
If only UDP is enabled, increase the number
of redundant packets.
Level 1~2: 3 Redundant packets
Level 3: 4 Redundant packets
4-7 IP Fax preamble wait time setting
Selects the preamble wait time.
[00 to 0f]
There are 16 values in this 4-bit binary
switch combination.
Waiting time: set value level x 100 ms
Max: 0f (1500 ms) Min: 00 (No wait time)
The default is "0000" (00H).
IP Fax Switch 02 [SP No. 1-111-003]
No. FUNCTION COMMENTS
0
IP Fax bit signal reverse setting
0: Maker code setting
1: Internal bit switch setting
When "0" is selected, the bit signal reverse
method is decided by the maker code.
When "1" is selected, the bit signal reverse
method is decided by the internal bit switch.
When communicating between IP Fax
devices, LSB first is selected.)
1
IP Fax transmission speed setting
0: Modem speed
1: No limitation
Selects the transmit speed for IP Fax
communication.
