Jam Detection
SM Appendix 7-3 D037/D038/D040/D041
Appendix:
Jam
Detection
Jam Code
SP
Display Description
LCD
Display
7504 24 Inverter Sn: ON Inverter sensor does not detect paper. C
7504 25 Duplex Exit: ON
Duplex exit sensor does not detect
paper.
Z
7504 27 Duplex Entrance: ON
Duplex entrance sensor does not detect
paper.
Z
7504 28 1-Bin Exit Sensor
1-bin tray exit sensor does not detect
paper.
C
7504 29 R-tray Paper Exit: ON
Paper exit sensor of the side tray does
not detect paper.
C
7504 51
Vertical Transport
Sensor1
Vertical transport sensor 1 does not turn
off.
A1, A2
7504 52
Vertical Transport
Sensor2
Vertical transport sensor 2 does not turn
off.
Y
7504 53
Vertical Transport
Sensor3
Vertical transport sensor 3 does not turn
off.
Y
7504 57 Registration Sensor Registration sensor does not turn off. B
7504 58
Fusing Entrance
Sensor
Fusing entrance sensor does not turn
off.
C
7504 59 Fusing Exit Sensor Fusing exit sensor does not turn off. C
7504 60 Exit Sensor Paper exit sensor does not turn off. C
7504 64 Inverter Sensor Inverter sensor does not turn off. C
7504 65 Duplex Exit Sensor Duplex exit sensor does not turn off. Z
7504 67
Duplex Entrance
Sensor
Duplex entrance sensor does not turn
off.
Z
7504 68 1-Bin Exit: ON 1-bin tray exit sensor does not turn off. R
