Ricoh Aficio MP C2050 Service Manual

System Service Mode
D037/D038/D040/D041 9-30 SM Appendix
[Color Regist Adjust] FA
2101
These values are the parameters for the automatic line position adjustment
and are adjusted at the factory. However, you must input a value for
SP2101-001 after replacing the laser optics housing unit. For details, see
"Laser Optics Housing Unit" in the "Replacement and Adjustment" section. The
value should be provided with the new laser optics housing unit.
001 Bk: Main Scan: Dot *ENG
002 C Main Scan: Dot *ENG
003 M Main Scan: Dot *ENG
004 Y Main Scan: Dot *ENG
[–512 to 511 / 0 / 1 dot/step]
013 Bk: Sub Scan: Line *ENG
014 C: Sub Scan: Line *ENG
015 M: Sub Scan: Line *ENG
016 Y: Sub Scan: Line *ENG
[–16384 to 16383 / 0 / 1 line/step]
2102 [Magnification Adjust] DFU
001 Main Mag.: Bk:High Spd *ENG
003 Main Mag.: Bk:Low Spd *ENG
004 Main Mag.: C:High Spd *ENG
006 Main Mag.: C:Low Spd *ENG
007 Main Mag.: M:High Spd *ENG
009 Main Mag.: M:Low Spd *ENG
010 Main Mag.: Y:High Spd *ENG
012 Main Mag.: Y:Low Spd *ENG
These are results of the main scan
length adjustment.
[0 to 560 / 280 / 1 /step]
