System Service Mode
SM Appendix 9-45 D037/D038/D040/D041
Appendix:
SP Mode
Tables
038 S. Cor.: 1200 Subdot: M *ENG
[–1 to 1 / 0 / 0.001 line/step]
039 Skew: Y *ENG
040 Bent: Y *ENG
041 M. Scan Shift: Left: Y *ENG
042 M. Scan Shift: Center: Y *ENG
043 M. Scan Shift: Right: Y *ENG
044 S. Scan Shift: Left: Y *ENG
045 S. Scan Shift: Center: Y *ENG
046 S. Scan Shift: Right: Y *ENG
[–5000 to 5000 / 0 / 0.001 um/step]
047 M. Cor.: Dot: Y *ENG
[–512 to 511 / 0 / 1 dot/step]
048 M. Cor.: Subdot: Y *ENG
[–15 to 15 / 0 / 1 pulse/step]
049 Paper Int. Mag: Subdot: Y *ENG
050 Mag.Cor. Subdot: Y *ENG
051 M. Left Mag.: Subdot: Y *ENG
052 M. Right Mag.: Subdot: Y *ENG
[–32768 to 32767 / 0 / 1 pulse/step]
053 S. Cor.: 600 Line: Y *ENG
[–16384 to 16383 / 0 / 1 line/step]
054 S. Cor.: 600 Subdot: Y *ENG
[–1 to 1 / 0 / 0.001 line/step]
055 S. Cor.: 1200 Line: Y *ENG
[–16384 to 16383 / 0 / 1 line/step]
056 S. Cor.: 1200 Subdot: Y *ENG
[–1 to 1 / 0 / 0.001 line/step]
057 S. Cor.: 600 Subdot *ENG
[–1 to 1 / 0 / 0.001 line/step]
058 Drum Cor.:600:Subdot *ENG
[–7 to 7 / 0 / 1 /step]
059 S. Cor.:1200 Subdot *ENG
[–1 to 1 / 0 / 0.001 line/step]
060 Drum Cor.:1200:Subdot *ENG
[–7 to 7 / 0 / 1 /step]
