System Service Mode
D037/D038/D040/D041 9-46 SM Appendix
2182
[Line Position Adj. Offset]
(Color) M. Scan: Main scan, S. Scan: Sub-scan
High / Medium: 120 mm/sec, Low: 60 mm/sec
001 C Magnification *ENG
002 M Magnification *ENG
003 Y Magnification *ENG
Adjusts the line position manually.
[-1 to 1 / 0 / 0.001%/step]
When line shifts are not corrected
by the automatic line position
adjustment, do this SP.
Increasing a value reduces the
image in the main scan direction.
Decreasing a value enlarges the
image in the main scan direction.
004 M. Scan: High: Dot: C *ENG
[-512 to 511 / 0 / 1 dot/step]
005 M. Scan: High: Subdot: C *ENG
[-15 to 15 / 0 / 1 pulse/step]
008 M. Scan: Low: Dot: C *ENG
[-512 to 511 / 0 / 1 dot/step]
009 M. Scan: Low: Subdot: C *ENG
[-15 to 15 / 0 / 1 pulse/step]
010 M. Scan: High: Dot: M *ENG
[-512 to 511 / 0 / 1 dot/step]
011 M. Scan: High: Subdot: M *ENG
[-15 to 15 / 0 / 1 pulse/step]
014 M. Scan: Low: Dot: M *ENG
[-512 to 511 / 0 / 1 dot/step]
015 M. Scan: Low: Subdot: M *ENG
[-15 to 15 / 0 / 1 pulse/step]
016 M. Scan: High: Dot: Y *ENG
[-512 to 511 / 0 / 1 dot/step]
017 M. Scan: High: Subdot: Y *ENG
[-15 to 15 / 0 / 1 pulse/step]
020 M. Scan: Low: Dot: Y *ENG
[-512 to 511 / 0 / 1 dot/step]
021 M. Scan: Low: Subdot: Y *ENG
[-15 to 15 / 0 / 1 pulse/step]
022 S. Scan: High: Dot: C *ENG
[-16384 to 16383 / 0 / 1 line]
023 S. Scan: High: Subdot: C *ENG
[–1 to 1 / 0 / 0.001 /line]
026 S. Scan: Low: Dot: C *ENG
[-16384 to 16383 / 0 / 1 line]
