Ricoh Aficio MP C2050 Service Manual

System Service Mode
D037/D038/D040/D041 9-230 SM Appendix
Sets the maximum number of channels available for data transmission via the
wireless LAN. The number of channels available varies according to location.
The default settings are set for the maximum end of the range for each area.
Adjust the upper 4 bits to set the maximum number of channels. DFU
 Do not change the setting.
Channel MIN *CTL
[1 to 11 or 13 / 1 / 1 /step]
Europe: 1 to 13
NA/ Asia: 1 to 11
007
Sets the minimum number of channels available for data transmission via the
wireless LAN. The number of channels available varies according to location.
The default settings are set for the minimum end of the range for each area.
Adjust the lower 4 bits to set the minimum number of channels. DFU
 Do not change the setting.
008 Transmission Speed *CTL
[0 x 00 to 0 x FF / 0 x FF to Auto / -]
0 x FF to Auto [Default]
0 x 11 – 55M Fix
0 x 10 – 48M Fix
0 x 0F – 36M Fix
0 x 0E – 18M Fix
0 x 0D – 12M Fix
0 x 0B – 9M Fix
0 x 0A – 6M Fix
0 x 07 – 11M Fix
0 x 05 – 5.5M Fix
0 x 08 – 1M Fix
0 x 13 – 0 x FE (reserved)
0 x 12 – 72M (reserved)
0 x 09 – 22M (reserved)
011 WEP key Select *CTL
Selects the WEP key.
[00 to 11 / 00 / 1 binary]
00: Key #1
