Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-231 D037/D038/D040/D041
Appendix:
SP Mode
Tables
01: Key #2 (Reserved)
10: Key #3 (Reserved)
11: Key #4 (Reserved)
042 Fragment Thresh *CTL
Adjusts the fragment threshold for the
IEEE802.11 card.
[256 to 2346 / 2346 / 1]
This SP is displayed only when the
IEEE802.11 card is installed.
043 1g CTS to Self *CTL
Determines whether the CTS self
function is turned on or off.
[0 to 1 / 1 / 1] 0: Off, 1: On
This SP is displayed only when the
IEEE802.11 card is installed.
044 11g Slot Time *CTL
Selects the slot time for IEEE802.11.
[0 to 1 / 0 / 1] 0: 20 µm, 1: 9 µm
045 WPA Debug Lvl *CTL
Selects the debug level for WPA
authentication application.
[1 to 3 / 3 / 1] 1: Info, 2: warning, 3: error
This SP is displayed only when the
IEEE802.11 card is installed.
5841 [Supply Name Setting]
001 Toner Name Setting: Black
002 Toner Name Setting: Cyan
003 Toner Name Setting: Yellow
004 Toner Name Setting: Magenta
007 OrgStamp
011 Staple Std1
012 Staple Std2
*CTL Specifies supply names. These
appear on the screen when the
user presses the Inquiry button
in the user tools screen.
