Page #766 background imageLoading...
Page #766 background image
System Service Mode
D037/D038/D040/D041 9-232 SM Appendix
013 Staple Std3
014 Staple Std4
5842 [GWWS Analysis Mode] DFU
001 Setting 1 *CTL
Default: 00000000 – do not change
Netfiles: Jobs to be printed from the
document server using a PC and the
DeskTopBinder software
002 Setting 2 *CTL
Adjusts the debug program modesetting.
Bit7: 5682 mmseg-log setting
0: Date/Hour/Minute/Second
1: Minute/Second/Msec.
0 to 6: Not used
5844 [USB]
Transfer Rate *CTL
0x01: Full speed
0x04: Auto Change
001
Adjusts the USB transfer rate.
002 Vendor ID *CTL
Displays the vendor ID. DFU
003 Product ID *CTL
Displays the product ID. DFU
004
Device Release
Number
*CTL
Displays the development release
version number. DFU
100 Notify Unsupport *CTL -
[Delivery Server Setting]
*CTL -
5845
Provides items for delivery server settings.
001 FTP Port No.
[0 to 65535 / 3670 / 1 /step]
