Page #781 background imageLoading...
Page #781 background image
System Service Mode
SM Appendix 9-247 D037/D038/D040/D041
Appendix:
SP Mode
Tables
2: Forbid print function (1)
3: Forbid fax TX (1)
4: Forbid scan sending (1)
5: Forbid downloading (1)
6: Forbid delete (1)
7: Reserved
050 DocSvr Format
Selects the display type for the document
box list.
[0 to 2 / 0 / 1]
0: Thumbnail, 1: Icon, 2: Details
051 DocSvr Trans
Sets the number of documents to be
displayed in the document box list.
[5 to 20 / 10 / 1]
100 Set Signature -
101 Set Encryption
Determines whether the scanned
documents with the WIM are encrypted
when they are transmitted by an e-mail.
[0 to 1 / 0 / 1]
0: Not encrypted, 1:Encryption
200 Detect Mem Leak -
201 DocSur Timeout -
[SD Get Counter]
5887
This SP determines whether the ROM can be updated.
001 - *CTL
This SP sends a text file to an SD card
inserted in SD card Slot 2 (lower slot).
The operation stores. The file is stored in
a folder created in the root directory of the
SD card called SD_COUNTER. The file is
saved as a text file (*.txt) prefixed with the
number of the machine.

Table of Contents

Other manuals for Ricoh Aficio MP C2050

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio MP C2050 and is the answer not in the manual?

Ricoh Aficio MP C2050 Specifications

Ricoh Aficio MP C2050

General Specifications IconGeneral Specifications
output speed20 ppm BW & Full-Color
warm-up time25 seconds
first copy time full-color9.5 seconds
copy resolution600 x 600 dpi
original capacity50 sheets
dimensions23.1" x 25.8" x 33.3" (587 x 655 x 845 mm)
weight220 lbs
power requirements120V, 60Hz, 12A
Printer Controller IconPrinter Controller
cpuRM7035C @ 533MHz
memory768 MB (512 MB + 256 MB) RAM (Standard); 1GB RAM (Maximum)
max. print speed20 ppm BW & Full-Color
max. print resolution1200 x 1200 dpi
standard interfaces10Base-T/100Base-TX Ethernet (RJ-45), USB 2.0 Device, USB 2.0 Host I/F
Scanner Specifications IconScanner Specifications
scanner resolutionFrom 100 to 600 dpi (1200 dpi for TWAIN)
scanning speed bw41 ipm
scanning speed full-color26 ipm
scan area main scan11.7" (297mm)
scan area sub scan17" (432mm)

Ricoh Aficio MP C2550

General Specifications IconGeneral Specifications
output speed25 ppm BW & Full-Color
warm-up time25 seconds
first copy time full-color9.5 seconds
copy resolution600 x 600 dpi
original capacity50 sheets
dimensions23.1" x 25.8" x 33.3" (587 x 655 x 845 mm)
weight220 lbs
power requirements120V, 60Hz, 12A
Printer Controller IconPrinter Controller
cpuRM7035C @ 533MHz
memory768 MB (512 MB + 256 MB) RAM (Standard); 1GB RAM (Maximum)
max. print speed25 ppm BW & Full-Color
max. print resolution1200 x 1200 dpi
standard interfaces10Base-T/100Base-TX Ethernet (RJ-45), USB 2.0 Device, USB 2.0 Host I/F
Scanner Specifications IconScanner Specifications
scanner resolutionFrom 100 to 600 dpi (1200 dpi for TWAIN)
scanning speed bw41 ipm
scanning speed full-color26 ipm
scan area main scan11.7" (297mm)
scan area sub scan17" (432mm)
