Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-251 D037/D038/D040/D041
Appendix:
SP Mode
Tables
Adjusts the side-to-side and leading registration of originals with the ARDF.
001 S-to-S Registration 1st
002 S-to-S Registration 2nd
[-3.0 to 3.0 / 0 / 0.1 mm/step ]
003 Leading Edge Registration
*ENG
[-5.0 to 5.0 / 0 / 0.1 mm/step ]
Adjusts the amount of paper buckle to correct original skew for the front and
rear sides.
005 Buckle: Duplex: 1st
006 Buckle: Duplex: 2nd
*ENG
[-5.0 to 5.0 / 0 / 0.1 mm/step ]
Adjusts the erase margin at the original trailing edge.
007 Trailing Edge Erase *ENG
[-5.0 to 5.0 / 0 / 0.1 mm/step ]
[ADF Input Check]
6007
Displays the signals received from the sensors and switches of the ARDF. Only
Bit 0 is used for ADF input check ( “Iutput Check Table” in this section").
[ADF Output Check]
6008
Activates the electrical components for functional check.
It is not possible to activate more than one component at the same time (
“Output Check Table” in this section")
[ADF Free Run]
6009
Performs a DF free run in simplex, duplex mode or stamp mode.
002 Free Run Duplex Mode -
[Stamp Position Adj.] Fax Stamp Position Adjustment
6010
Adjusts the horizontal position of the stamp on the scanned originals.
