System Service Mode
D037/D038/D040/D041 9-252 SM Appendix
6010 1 Stamp Position Adj. *ENG
[-5.0 to 5.0 / 0 / 1 mm/step]
[Original Size Detection Priority] Original Size Detection Priority
6016
Specifies the original size for a size detected by the original sensor, since
original sensors cannot recognize all sizes.
*ENG
[0 or 1 / 0 / - ]
0: Setting 1
1: Setting 2
Setting 1 Setting 2
DLT SEF Folio SEF 11" x 15"
LG SEF Foolscap SEF
LT SEF US EXE 8" x 10"
NA
LT LEF US EXE LEF
DLT SEF 8K 267 x 390 mm
LT SEF 16K 195 x 267 mm
001
Original Size Detection
Priority
EU/
ASIA
LT LEF 16K 267 x 195 mm
[DF Magnification Adj.] DF Magnification Adjustment
6017
Adjusts the magnification in the sub-scan direction for the ARDF.
001 DF Magnification Adj. *CTL
[-5.0 to 5.0 / 0 / 0.1 %/step]
[Staple Position Adjustment]
6101
Adjusts the staple position for finisher.
+ Value: Moves the staple position to the rear side.
- Value: Moves the staple position to the front side.
001 - ENG
[-2 to 2 / 0 / 0.2mm/step]
