Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-253 D037/D038/D040/D041
Appendix:
SP Mode
Tables
[Punch Position Adjustment]
6102
Adjusts the punching position in the sub scan direction.
001 Leading Edge Adjustment ENG
[-1.5 to 1.5 / 0 / 0.1mm/step]
[Jogger Position Adjustment]
6103
Adjusts the jogger position
001 - ENG
[-1.5 to 1.5 / 0 / 0.1mm/step]
[Punch Position Adjustment]
6104
Adjusts the punching position in the main scan direction.
001 Side-to-Side Adjustment ENG
[-2.0 to 2.0 / 0 / 0.2mm/step]
[Finisher Input Check] Finisher (D429)
6120
Displays the signals received from sensors and switches of the finisher. (
“Iutput Check Table” in this section")
[Finisher Output Check] Finisher (D429)
6121
Displays the signals received from sensors and switches of the finisher. (
“Output Check Table” in this section")
SP7-XXX (Data Log)
[Total SC Counter]
7401
Displays the number of SC codes detected.
001 SC Counter *CTL
[0 to 9999 / 0 / 1/step ]
