Page #794 background imageLoading...
Page #794 background image
System Service Mode
D037/D038/D040/D041 9-260 SM Appendix
When a unit is replaced, the machine automatically detects that the new unit
is installed. Then, the current PM counter value is automatically moved to the
PM Counter - Previous (SP7-906-1 to 10) and is reset to “0”.
The total number of sheets printed with the last unit replaced can be checked
with SP7-906-1 to 10.
NOTE: The LCT is counted as the 3rd feed station.
001 Paper
002 Page: PCU: Bk
003 Page: PCU: C
004 Page: PCU: M
005 Page: PCU: Y
006 Page: Development Unit: Bk
007 Page: Development Unit: C
008 Page: Development Unit: M
009 Page: Development Unit: Y
010 Page: Developer: Bk
011 Page: Developer: C
012 Page: Developer: M
013 Page: Developer: Y
014 Page: ITB Unit
015 Page: ITB Cleaning Unit
016 Page: Fusing Unit
017 Page: Fusing Roller
018 Page: Fusing Belt
019 Page:PTR Unit
