System Service Mode
SM Appendix 9-261 D037/D038/D040/D041
Appendix:
SP Mode
Tables
020 Page:ITB T-Collect Bottle
021 Page:PCU T-Collect Bottle
Displays the number of revolutions of motors or clutches for each current
maintenance unit.
[ 0 to 9999999 / 0 / 1 revolution/step ]
When a unit is replaced, the machine automatically detects that the new unit
is installed. Then, the current PM counter value is automatically moved to the
PM Counter - Previous (SP7-906-11 to 20) and is reset to “0”. The total
number of revolutions made with the last unit replaced can be checked with
SP7-906-11 to 20.
031 Rotation: PCU: Bk
032 Rotation: PCU: C
033 Rotation: PCU: M
034 Rotation: PCU: Y
035 Rotation: Development Unit: Bk
036 Rotation: Development Unit: C
037 Rotation: Development Unit: M
038 Rotation: Development Unit: Y
039 Rotation: Developer: Bk
040 Rotation: Developer: C
041 Rotation: Developer: M
042 Rotation: Developer: Y
043 Rotation:ITB Unit
044 Rotation: ITB Cleaning Unit
045 Rotation: Fusing Unit
046 Rotation: Fusing Roller
