Ricoh Aficio MP C2050 Service Manual

System Service Mode
D037/D038/D040/D041 9-262 SM Appendix
047 Rotation: Fusing Belt
048 Rotation: PTR Unit
[0 to 999999999 / - / 1 mm/step ]
Displays the value given by the following formula:
(Current revolution ÷ Target revolution) × 100. This shows how much of the
unit’s expected lifetime has been used up.
The Rotation% counter is based on rotations, not prints. If the number of
rotations reaches the limit, the machine enters the end condition for that unit.
If the print count lifetime is reached first, the machine also enters the end
condition, even though the R% counter is still less than 100%.
049 Amount:ITB T-Collect Bottle
050 Amount:PCU T-Collect Bottle
[0 to 999999999 / - / 1 mm/step ]
061 Rotation (%): PCU: Bk
062 Rotation (%): PCU: C
063 Rotation (%): PCU: M
064 Rotation (%): PCU: Y
065 Rotation (%): Development Unit: Bk
066 Rotation (%): Development Unit: C
067 Rotation (%): Development Unit:M
068 Rotation (%): Development Unit: Y
069 Rotation (%): Developer: Bk
070 Rotation (%): Developer: C
071 Rotation (%): Developer: M
072 Rotation (%): Developer: Y
073 Rotation (%): ITB Unit
*ENG [0 to 255 / - / 1 %/step]
