5803 70 Mechanical Counter: CMY: Set Set Not set
5803 71 Key Counter: Set Set Not set
5803 72 BCU Version - -
5803 77 Bank Feed Sensor 1 Paper detected Paper not detected
5803 78 Bank Feed Sensor 2 Paper detected Paper not detected
5803 79 Bank Feed Sensor 3 Paper detected Paper not detected
5803 80 Bank Vertical Feed Sensor 1 Paper detected Paper not detected
5803 81 Bank Vertical Feed Sensor 2 Paper detected Paper not detected
5803 82 Bank Vertical Feed Sensor 3 Paper detected Paper not detected
5803 83 Bank Cover Sensor 1
5803 84 Bank Cover Sensor 2
5803 94 GAVD Open/Close Detection - -
5803 200 Scanner HP Sensor Not HP HP
5803 201 Platen Cover Sensor Open Close
Table 1: Paper Size Switch (Tray 1)
Switch 1 is used for tray set detection.
0: Pushed, 1: Not pushed
Models Paper size sensor
North America Europe/Asia 1 2 3
A4 A4 0 1 1
LT LT 1 1 1
Exe Exe 1 1 0
HLT A5 0 0 0
- A6 1 0 0
3. SP Mode Tables
