Table 2: Paper Size Switch (Tray 2)
Switch 1 is used for tray set detection.
0: Pushed, 1: Not pushed
Models Paper size sensor
North America Europe/Asia 1 2 3
LG LG 0 0 0
A4 A4 0 1 1
HLT A5 0 1 0
LT LT 1 1 1
Exe Exe 1 1 0
A6 A6 0 0 1
B6, B5 B6, B5 1 0 0
Table 3: Paper Size Switch (Tray 3 and 4)
Switch 1 is used for tray set detection.
0: Pushed, 1: Not pushed
Models Paper size sensor
North America Europe/Asia 1 2 3
LG LG 0 0 0
A4 A4 0 1 1
HLT A5 0 1 0
LT LT 1 1 1
Exe Exe 1 1 0
A6 A6 0 0 1
B6, B5 B6, B5 1 0 0
Input and Output Check
437
