5804 92 Toner Supply Motor: M -

5804 93 Toner Supply Motor: C -

5804 94 Toner Supply Motor: Y -

5804 95 LDU Shutter Motor: CW -

5804 96 LDU Shutter Motor: CCW -

5804 100 Fusing Fan: H -

5804 101 Fusing Fan: L -

5804 102 Fusing Fan 1: H -

5804 103 Fusing Fan 1: L -

5804 104 Polygon Motor: Standard Speed -

5804 105 Polygon Motor: Middle Speed -

5804 106 Polygon Motor: Low Speed -

5804 107 Fusing Fan 2: H -

5804 108 Fusing Fan 2: L -

5804 109 Fusing Front Fan: H -

5804 110 Fusing Front Fan: L -

5804 111 Toner Supply Fan -

5804 112 Drive Unit Fan -

5804 113 Development Fan 1

5804 114 Development Fan 2 -

5804 115 Development Fan -

5804 116 Laser Unit Fan -

5804 117 Feed Fan -

5804 118 PSU Fan -

5804 120 Development Clutch -

5804 121 By-pass Solenoid -

Input and Output Check

441
