5804 122 1 Tray Lock Solenoid -

5804 123 1 Tray Feed Solenoid -

5804 124 Junction Gate Solenoid 1 -

5804 125 Junction Gate Solenoid 2 -

5804 130 PP: Charge DC: Y -

5804 131 PP: Charge DC: M -

5804 132 PP: Charge DC: C -

5804 133 PP: Charge DC: K -

5804 134 PP: Development: Y -

5804 135 PP: Development: M -

5804 136 PP: Development: C -

5804 137 PP: Development: K -

5804 138 PP: D -

5804 139 PP: T1: Y -

5804 140 PP: T1: M -

5804 141 PP: T1: C -

5804 142 PP: T1: K -

5804 143 PP: T2: + -

5804 144 PP: T2: - -

5804 147 PP: Charge AC: Y: 260mm/s -

5804 148 PP: Charge AC: Y: 182mm/s -

5804 149 PP: Charge AC: Y: 85mm/s -

5804 154 PP: Charge AC: M: 260mm/s -

5804 155 PP: Charge AC: M: 182mm/s -

5804 156 PP: Charge AC: M: 85mm/s -

5804 161 PP: Charge AC: C: 260mm/s -
