3212 [Vt Shift :Set]
011 Low Spd:K *ENG
Sets the correction value at low speed to
correct Vt shift for each color.
[0.00 to 5.00 / 0.31 / 0.01V/step]
012 Low Spd:C *ENG
013 Low Spd:M *ENG
014 Low Spd:Y *ENG
3213 [Vt Shift :Set]
001 TC Cor.(ON/OFF) *ENG
[0 or 1 / 1 / 1/step]
0:OFF, 1:ON
021 TC Low Spd:K *ENG
[-0.50 to 0.50 / 0.00 / 0.01V/step]
022 TC Low Spd:C *ENG
023 TC Low Spd:M *ENG
024 TC Low Spd:Y *ENG
3214 [Vt Save :Set]
001 Coverage Thresh *ENG [0 to 100 / 20 / 1%/step]
3218 [Vt Err Flag :Disp]
001 UppErr Flag: K *ENG
Displays the flag "1" to indicate Vt exceeds
upper limit error threshold (SP3211-002).
[0 or 1 / - / 1/step]
002 UppErr Flag: C *ENG
003 UppErr Flag: M *ENG
004 UppErr Flag: Y *ENG
011 LowErr Flag: K *ENG
Displays the flag "1" to indicate Vt falls below
the lower limit error threshold (SP3211-004).
[0 or 1 / - / 1/step]
012 LowErr Flag: C *ENG
013 LowErr Flag: M *ENG
014 LowErr Flag: Y *ENG
3219 [TD.Sens:Vt':Disp]
3. SP Mode Tables
186
