3210 [TD.Sens:Vt :Disp]
001 Current: K *ENG
Displays the latest TD sensor output for each
color.
[0.00 to 5.50 / - / 0.01V/step]
002 Current: C *ENG
003 Current: M *ENG
004 Current: Y *ENG
3211 [Vt Limits Err :Disp]
002 Upper Threshold *ENG
Sets Vt upper limit threshold to detect upper
limit error.
[0.00 to 5.00 / 4.70 / 0.01V/step]
003
Thresh Num of
UpperCounter
*ENG
Sets the number of times to exceed the Vt upper
limit threshold to determine the Vt upper limit
error (SC360 to 363).
[0 to 500 / 280 / 1times/step]
004 Lower Threshold *ENG
Sets Vt upper lower threshold to detect lower
limit error.
[0.00 to 5.00 / 0.50 / 0.01V/step]
005
Threshold Num of
LowerCounter
*ENG
Sets the number of times to fall below the Vt
lower limit threshold to determine the Vt lower
limit error (SC365 to 368).
[0 to 500 / 140 / 1times/step]
011 Upper Counter: Bk *ENG
Displays the number of times that Vt for each
color exceeds to Vt upper limit threshold.
[0 to 500 / - / 1 times /step]
012 Upper Counter: C *ENG
013 Upper Counter: M *ENG
014 Upper Counter: Y *ENG
021 Lower Counter: Bk *ENG
Displays the number of times that Vt for each
color falls below to Vt lower limit threshold.
[0 to 500 / - / 1 times /step]
022 Lower Counter: C *ENG
023 Lower Counter: M *ENG
024 Lower Counter: Y *ENG
Main SP Tables-3
185
