011 Initial: K *ENG
Displays the target value of TD sensor output
voltage at TD sensor initial settings execution.
[0.00 to 5.00 / - / 0.01V/step]
012 Initial: C *ENG
013 Initial: M *ENG
014 Initial: Y *ENG
021 Pixel Correction: K *ENG
Displays the pixel correction value of Vtref
correction with image coverage.
[-5.00 to 5.50 / - / 0.01V/step]
022 Pixel Correction: C *ENG
023 Pixel Correction: M *ENG
024 Pixel Correction: Y *ENG
3231 [Vtref Limits :Set]
001 Upper:K *ENG
Sets the upper limit of Vtref (target value of TD
sensor output voltage).
[0.00 to 5.00 / 4.00 / 0.01V/step]
002 Upper:C *ENG
003 Upper:M *ENG
004 Upper:Y *ENG
011 Lower:K *ENG
Sets the lower limit of Vtref (target value of TD
sensor output voltage).
[0.00 to 5.00 / 2.00 / 0.01V/step]
012 Lower:C *ENG
013 Lower:M *ENG
014 Lower:Y *ENG
3232 [Vtref Correct:Pixel]
001 ON/OFF *ENG
[0 or 1 / 1:ON /1/step]
0:OFF, 1:ON
011 Low Coverage Coef:K *ENG
Sets the coefficient Vtref to determine the Vtref
correction value with low image coverage.
[0.0 to 5.0 / 0.3 / 0.1/step]
012 Low Coverage Coef:C *ENG
013 Low Coverage Coef:M *ENG
014 Low Coverage Coef:Y *ENG
3. SP Mode Tables
188
