021 High Coverage Coeff:K *ENG
Sets the coefficient Vtref to determine the Vtref
correction value with high image coverage.
[0.0 to 5.0 / 0.4 / 0.1/step]
022 High Coverage Coeff:C *ENG
023 High Coverage Coeff:M *ENG
024 High Coverage Coeff:Y *ENG
040 Initial ProCon Thresh *ENG
Sets process control flag and executes process
control by determining the high image
coverage is successive if the cumulative
average (M) of image coverage (SP3224-009
to 012) is more than the specified value.
[0 to 255 / 6 / 1times/step]
041 High Coverage Thresh:H *ENG
This SP is referenced when an output of high
image coverage.
[0 to 100 / 60 / 1%/step]
050 ProCon Thresh *ENG [0 to 255 / 14 / 1times/step]
060 Low Coverage Thresh *ENG
This SP is referenced when an output of low
image coverage.
[0.0 to 20.0 / 3.0 / 0.1%/step]
070 TC Upper Limit Correction *ENG
Sets Vtref lower limit (TC upper limit) which can
be canceled temporarily by determining the
low image coverage is successive if the
cumulative average (L) of image coverage
(SP3224-013 to 016) is less than the specified
value.
[0.0 to 5.0 / 0.5 / 0.1wt%/step]
071 TC Upper Limit:Display:Bk *ENG Displays Vtref lower limit (TC upper limit) which
can be canceled temporarily by determining
the low image coverage is successive if the
cumulative average (L) of image coverage
(SP3224-013 to 016) is less than the specified
value.
[1.0 to 15.0 / - / 0.1wt%/step]
072 TC Upper Limit:Display:C *ENG
073 TC Upper Limit:Display:M *ENG
074 TC Upper Limit:Display:Y *ENG
3234 [Vtref Corr :Disp/Set]
Main SP Tables-3
189
