020 Interval :Set *ENG
Sets Vsg adjustment execution Page interval
determined during printing or at the end of
printing.
Note: Vsg adjustment is executed when process
control or MUSIC requires the execution. (Not
executed by it.)
[0 to 2000 / 500 / 1page/step]
021 Page Cnt *ENG
Displays Page counter used Vsg execution
determination.
[0 to 2000 / - / 1page/step]
3321 [Adjusted Vsg]
001 Vsg reg *ENG
Displays normal reflection light output from
bared belt with Vsg adjustment.
[0.00 to 5.50 / - / 0.01V/step]
011 Vsg dif *ENG
Displays diffused reflection light output from
bared belt with Vsg adjustment.
[0.00 to 5.50 / - / 0.01V/step]
021 Vsg reg(BW) *ENG
Displays normal reflection light output from
bared belt with Vsg adjustment.
[0.00 to 5.50 / - / 0.01V/step]
031 Vsg dif(BW) *ENG
Displays diffused reflection light output from
bared belt with Vsg adjustment.
[0.00 to 5.50 / - / 0.01V/step]
041 Vsg TM(Front) *ENG
Displays normal reflection light output from
bared belt with Vsg adjustment (TM_Front,
TM_Center or TM_Rear sensor).
[0.00 to 5.50 / - / 0.01V/step]
042 Vsg TM(Center) *ENG
043 Vsg TM(Rear) *ENG
3322
[Adjusted Ifsg]
Displays the result value of the Vsg adjustment for each sensor.
001 Ifsg *ENG
Displays Vsg adjusted ID sensor LED current.
[0.0 to 50.0 / - / 0.1mA/step]
3. SP Mode Tables
194
