011 Ifsg *ENG
Displays Vsg adjusted ID sensor LED current.
[[0.0 to 50.0 / - / 0.1mA/step]
021 Ifsg: TM(Front) *ENG
Displays Vsg adjusted ID sensor LED current
(TM_Front, TM_Center or TM_Rear sensor).
[0.0 to 50.0 / - / 0.1mA/step]
022 Ifsg: TM(Center) *ENG
023 Ifsg: TM(Rear) *ENG
3323 [Vsg Adj OK?]
001 Latest *ENG
Displays Vsg adjustment execution result.
[0 to 999 / - / 1/step]
002 Latest 1 *ENG
003 Latest 2 *ENG
004 Latest 3 *ENG
005 Latest 4 *ENG
006 Latest 5 *ENG
007 Latest 6 *ENG
008 Latest 7 *ENG
009 Latest 8 *ENG
010 Latest 9 *ENG
3330 [ID.Sens Coef :Disp]
001 K2(Latest) *ENG Displays the latest value for the sensitivity
correction coefficient (K2 or K5) of ID sensor.
[0.0000 to 5.0000 / - / 0.0001/step]
011 K5(Latest) *ENG
3331 [ID.Sens Coef :Set]
001 K2: Upp Limit Corr *ENG [-0.20 to 0.40 / 0.07 / 0.01/step]
002 K2: Lwr Limit Corr *ENG [-0.40 to 0.20 / -0.07 / 0.01/step]
003 K2: Upp/Lwr Limit Coef1 *ENG [0.00 to 1.00 / 0.00 / 0.01/step]
Main SP Tables-3
195
