5858
[Debug Save When]
These SPs select the content of the debugging information to be saved to the destination
selected by SP5857-002.
SP5858-3 stores one SC specified by number. Refer to Section 4 for a list of SC error
codes.
001
Engine SC Error *CTL
[0 or 1 / 0 / 1/step]
0: OFF, 1: ON
Turns on/off the debug save for SC codes generated by printer engine errors.
002
Controller SC Error *CTL
[0 or 1 / 0 / 1/step]
0: OFF, 1: ON
Turns on/off the debug save for SC codes generated by GW controller errors.
003 Any SC Error *CTL [0 to 65535 / 0 / 1/step]
004
Jam *CTL
[0 or 1 / 0 / 1/step]
0: OFF, 1: ON
Turns on/off the debug save for jam errors.
5859
[Debug Save Key No.]
These SPs allow you to set up to 10 keys for log files for functions that use common
memory on the controller board.
3. SP Mode Tables
352
