002 Mode b ENG
[Execute]
Executes the fine line position adjustment
once.
If this SP is not completed, do
SP2111-003 first and then try this SP
again
003 Mode c ENG
[Execute]
Executes the rough line position adjustment
once.
After doing this SP, make sure to execute
SP2111-001 or -002. Otherwise, the line
position adjustment is not perfectly done.
004 Mode d ENG
[Execute]
Executes the fine line position adjustment
and rough line position adjustment.
2112
[TM/ID Sensor Test]
This SP is used to check the ID sensors at the factory. The results of this SP are displayed in
SP2140 to SP2145.
001 TM/ID Sensor Check *ENG [Execute]
010 General:FCRP *ENG [0 to 9999 / - / 1/step]
020 Threshold Setting *ENG [0.00 to 5.50 / 1.90 / 0.01V/step]
2117
[Skew Adjustment]
Specifies a skew adjustment value for the skew motor M, C, Y or Bk.
001 Ma:Skew Adjustment *ENG
[–256 to 256 / 0 / 1 click/step]
002 Cy:Skew Adjustment *ENG
003 Ye:Skew Adjustment *ENG
004 Bk:Skew Adjustment *ENG
5. System Maintenance
354
