Ricoh AFICIO MP C305SP - Page 643

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
The polygon mirror motor does not leave the READY status within the given time
after the polygon motor switches off.
• Disconnected or defective harness to polygon motor driver board
•
Defective polygon motor driver board
•
Defective polygon motor
1. Check or replace the harness.
2. Replace the polygon motor.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
204
-01
D Polygon motor error 0: XSCRDY signal error: Bk, Cy
-03 D Polygon motor error 1: XSCRDY signal error: Ma, Ye
The SCRDY_N signal goes HIGH (inactive) during a writing operation.
• Disconnected or defective harness to polygon motor driver board
• Defective polygon motor
•
Defective polygon motor driver board
1. Check or replace the harness.
2. Replace the polygon motor.
3. Replace the BICU.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
220
-01
D Laser synchronizing detection error: start position LD1: Bk
-02 D Laser synchronizing detection error: start position LD1: Ma
SC Tables
641
