12. Place the platen sheet [A] on the exposure glass.
13. Line up the rear left corner of the platen sheet flush against corner [B] on the exposure glass.
14.
Remove the protection seals [C].
15. Close the ARDF.
16. Reopen the ARDF.
17. Press the surface of the platen sheet gently to attach it securely on the ARDF.
18. Adjust the ARDF registration (front / back) (
p.160).
ARDF (D606)
77
