10. Remove two screws [A] on the controller board. These screws will be used for attaching the
bracket.
11. With the HDD label side facing down, connect the connector of the HDD with the connection
bracket to CN710 [B] ( x 1).
12. Attach the HDD with the connection bracket [C] to the controller box ( [A] x 2).
2. Installation
92
