How is the signal strength when using the wireless LAN?
802.11 Ad hoc Mode
Either move to a location where the signal is good, or remove obstructions.
Infrastructure Mode
Check the signal status from the [Maintenance] menu on the control panel. If the signal is poor, either
move to a location where it is good, or remove obstructions.
Checking the Port Connection
When the printer is directly connected via the PC cable and the data-in indicator does not flash or light up,
the method of checking the port connection is as follows.
• For a parallel port connection, port LPT 1 or LPT 2 should be set.
• For a USB port connection, port USB00 (n)
*1
should be set.
*1
(n) is the number of printers connected.
For Windows 2000:
1. On the [Start] menu, point to [Settings], and then click [Printers].
2. Click to select the icon of the printer. Next, on the [File] menu, click [Properties].
3. Click the [Port] tab.
4. Check the [Print to the following port] box to confirm that the correct port is selected.
For Windows XP Professional, Windows Server 2003/2003 R2/2008:
1. On the [Start] menu, click [Printers and Faxes].
2. Click to select the icon of the printer. Next, on the [File] menu, click [Properties].
3. Click the [Port] tab.
4. Check the [Print to the following port(s).] box to confirm that the correct port is selected.
For Windows XP Home Edition:
1. On the [Start] menu, click [Control Panel].
2. Click [Printers and Other Hardware].
3. Click [Printers and Faxes].
4. Click to select the icon of the printer. Next, on the [File] menu, click [Properties].
5. Click the [Port] tab.
6. Check the [Print to the following port(s).] box to confirm that the correct port is selected.
Printer Does Not Print
169
