4. Configuration
This chapter explains supported network connections, and settings for the IP addresses and the Wireless
LAN security.
Ethernet Configuration
Configure the following network settings according to the network interface you are using.
You can use SmartDeviceMonitor for Admin or a Web browser to configure IP address-related settings in
a TCP/IP-capable environment.
• Configure the printer for the network using the control panel.
• The following table shows the control panel settings and their default values. These items appear in
the [Host Interface] menu.
Setting Name Value
IPv4 Settings • DHCP: On
• IPv4 Address: 11.22.33.44
• Subnet Mask: 0.0.0.0
• Gateway Address: 0.0.0.0
IPv6 Settings Stateless Sett.: Active
IPsec Not Active
Frame Type (NW) Auto Select
Active Protocol • IPv4: Active
• IPv6: Not Active
• NetWare: Active
• SMB: Active
• AppleTalk: Active
Ethernet Speed Auto Select
IEEE802.1X Auth Not Active
LAN Type Ethernet
61
