Installing the Gigabit Ethernet Board
• The printer's Ethernet and USB ports are not available when the Gigabit Ethernet board is attached
to the printer. Use the Ethernet and USB ports on the Gigabit Ethernet board.
• Before you begin any installation, always ground yourself by touching something metal to discharge
any static electricity. Static electricity can damage the Gigabit Ethernet board.
• Do not subject the Gigabit Ethernet board to physical shocks.
1. Check the package contains the following:
1. Gigabit Ethernet Board
2. Protective caps (one each for the Ethernet port and the USB port)
3. Ferrite Core
2. Turn off the power, and then unplug the power cable.
3. Disconnect the cables from the Ethernet port and the USB port of the printer, and cover each
port with its protective cap.
To Next Page
