10. Push the fusing unit until it stops.
BMU073S
11. Push the lock levers of the fusing unit down until they click.
BMU074S
Proceed to step 13 if the optional duplex unit is installed.
12. Position the rear cover horizontally and align it with the grooves in the printer's interior.
BMU075S
10. Removing Misfed Paper
196
10
