4. Align the holes over the pins, and then lower the printer gently onto the paper feed unit.
There are three pins on the top of the paper feed unit that point straight up. On the bottom of the
printer, there are three holes.
5. Attach the interface cable to the printer.
6. Plug the printer's power cord back into the wall outlet, and then turn on the power.
• After finishing installation, you can check whether the paper feed unit is properly installed: Print the
configuration page from the [List/Test Print] menu. If it is installed properly, you will see "Paper Feed
2. Installing Options
28
