• The issuing location may not be displayed if you request two certificates at the same time. When you
install a certificate, be sure to check the certificate destination and installation procedure.
• Using Web Image Monitor, you can create the contents of the device certificate but you cannot send
the certificate application.
• Click [Cancel Request] to cancel the request for the device certificate.
Installing the Device Certificate (Certificate Issued by a Certificate Authority)
Install the device certificate using Web Image Monitor. For details about the displayed items and selectable
items, see Web Image Monitor Help.
This section explains the use of a certificate issued by a certificate authority as the device certificate.
Enter the device certificate contents issued by the certificate authority.
1. Open a Web browser.
2. Enter "http://(the machine's IP address or host name)/" in the address bar.
When entering an IPv4 address, do not begin segments with zeros. For example: If the address is
"192.168.001.010", you must enter it as "192.168.1.10" to connect to the machine.
The top page of Web Image Monitor appears.
3. Click [Login].
The administrator can log on.
Enter the login user name and login password.
4. Click [Configuration], and then click [Device Certificate] under "Security".
The "Device Certificate" page appears.
5. Check the radio button next to the number of the certificate you want to install.
6. Click [Install].
7. Enter the contents of the device certificate.
In the "Certificate Request" box, enter the contents of the device certificate received from the certificate
authority.
8. Click [OK].
"Installed" appears under "Certificate Status" to show that a device certificate for the machine has
been installed.
9. Click [Logout].
Enabling SSL
After installing the device certificate in the machine, enable the SSL setting.
Protection Using Encryption
341
