Replace Maintenance Kit
10
1
B Lift the lock levers of the fusing
unit as shown in the illustration.
C Pull the fusing unit out.
D Pull out the pins on the both sides
of the new fusing unit.
E Push the new fusing unit into the
printer.
F Push the lock levers of the fusing
unit down until they click.
AUB311S
AUB312S
AUB313S
AUB314S
AUB315S
SincereP1_pera_maintkitA-GB_F_FM_forPaper.book Page 10 Monday, October 16, 2006 3:48 PM
