31 October 2001 TIMING CHART
6-41
Detailed
Descriptions
(1) When the cutter has cut the master, the pressure plate goes to the home position, the drum rotates, and the
pressure release solenoid, paper delivery motor, vacuum fan motor and air knife fan motor all turn on.
(2) When the drum is at the feed start timing sensor plus a feed delay time (X), the paper feed motor turns on. X
depends on the selected printing speed.
(3) After a certain time (Y), the registration motor turns on.
(4) When the drum is at the paper exit timing sensor, the solenoid turns off.
