DRUM
31 October 2001
3-26
3.8.5
INK ROLLER UNIT / INK ROLLER ONE-WAY CLUTCH
•
Metal screen (
☛
3.
8.3)
•
Pump covers (
☛
3.8.4)
[A]:
Board cov
er (
!
x 2)
[B]:
Front stay (
"
x 2
,
!
x 3
)
[C]: Front
flange
[D]:
Rear stay (
!
x 2)
[E]:
Rear stopper
s (
!
x 1)
[F]: Ring
[G]: Rear
flange
[H]:
Ink roller unit
[I]:
Ink roller one-w
ay clutch
C238R023.
W
MF
C238R060.W
MF
C238R033.
W
MF
[D]
[E]
[F]
[G]
[E]
[I]
[H]
[A]
[B]
[C]
60
62
