MAIN MENU NO.8: SYSTEM TEST 31 October 2001
5-14
5.9 MAIN MENU NO.8: SYSTEM TEST
5.9.1 SP TABLE
No. Menu Items Default Settings
8-1 Download main firmware No No/Ld (☛ 5.9.2)
8-2 Upload main firmware No No/Ld (☛ 5.9.3)
8-10 Test patterns 6 1 to 9 (☛ 5.9.4)
8-20 Free run - scanner Off Off/On
8-21 Paper feed (15 rpm) 0 (☛ 5.9.5)
8-22 Free run - paper feed (15 rpm) 0 (☛ 5.9.6)
8-30 All indicators on the panel - Press # key
5.9.2 SP8-1: DOWNLOAD MAIN FIRMWARE
Purpose: This upgrades the main firmware using a flash memory card.
1. Before downloading new firmware, check the current version with SP1-70 (☛
5.2.2).
2. Prepare a flash memory card with the latest firmware.
3. Turn off the main switch and disconnect the power cord.
4. Remove the rear card cover.
5. Plug the flash memory card into the connector on the MPU.
6. Connect the power cord, then turn on the main switch.
7. Access SP8-1. Using the “1” key, select “Ld”.
8. Press the Enter key. (It takes about 2.0 minutes to complete.)
9. Check that the “End” is displayed.
10. Turn off the main switch, and remove the flash memory card.
