TIMING CHART 31 October 2001
6-38
6.9 TIMING CHART
6.9.1 MASTER EJECT / MASTER FEED
Press the start key
Wrapping the master
Open
Close
1.0 s
Check Check
43 degrees
Check
12.0 s
Master Eject Section Master Feed Section
Rotating at
regular intervals
5 mm
64.1mm
21.7 mm
550 mm
Master eject position SN
Feed start timing SN
Paper exit timing SN
Clamper close SN
Clamper open SN
Clamper motor
Master eject motor
Main motor (30 rpm)
Master eject SN
Pressure plate motor
Pressure plate HP SN
Pressure plate limit SN
Scanner HP SN
Scanner motor
Master feed motor
Cutter HP motor
Cutter motor
Cutting the master
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8) (9)
(10)
(10)
(11)
(12)
C238D044.WMF
