Service Call Conditions
M095/M096/M099/M100 5-12 SM
480
Agitator Motor Error
The agitator motor error is detected twice for 10 msec during the initialization at
power-on or after the cover is closed.
Disconnected or defective harness
Defective agitator motor
1. Check or replace the harness.
2. Replace the agitator motor.
490
ITB (Image Transfer Belt) Unit Set Error
The TM sensor does not detect the reflection from the ITB.
No ITB unit in the machine
Dirty TM sensor
1. Check the installation of the ITB unit.
2. Clean the TM sensor.
To Next Page
